JBL Studio 698 Floorstanding Speakers

What Is the JBL Studio 698?

The flagship of the Studio range and its only 3-way design: dual 8-inch woofers, a dedicated 6-inch midrange and a compression driver, with response to 40 kHz. It belongs to the JBL Studio range and is supplied as a single unit.

Key Features and What They Mean

Only features published by JBL are listed, with what each means in a real room.

• **Dedicated 6-inch midrange** — A separate driver for the vocal range — the main difference from the 2.5-way Studio 690.
• **Dual 8-inch PolyPlas® woofers** — Bass to 36 Hz for full-range stereo and large-room home theatre.
• **Compression driver in an HDI™ waveguide** — A compression driver is a technology JBL carries over from professional cinema and touring sound. It plays loud with low strain, which helps in larger rooms and at reference levels.

JBL Studio 698 Specifications

Values from JBL's manufacturer documentation, checked on 10 October 2026. Where JBL's own documents conflict or a figure isn't published, we leave it out instead of guessing. View the JBL source document.

What the Specifications Mean in Practice

How to read these numbers when planning your room.

• **Sensitivity 90 dB** — each 3 dB higher sensitivity means roughly half the amplifier power for the same loudness. This is an efficient speaker that most AV receivers drive comfortably.
• **Nominal impedance 6 ohms** — most current AV receivers are rated for 6-ohm speakers; we confirm the receiver's minimum rated load before pairing.
• **Recommended amplifier power Max 250 W** — this is a range, not a requirement to buy the largest amplifier. Room size and listening level decide what you need.
• No specification guarantees a listening result: room size, furnishings, placement and calibration change what you hear.

Best Use Cases

Applications the Studio 698 is designed for:

• Stereo music listening
• Front left/right in a 5.1, 7.1 or Atmos home theatre
• Living-room systems without a subwoofer for music

Who Should Consider It — and Who May Prefer Another Option

**Consider it if:** Larger living rooms and dedicated home theatres that play loud, and listeners who want more scale than Stage 2. **You may prefer another configuration if:** Rooms where the speakers must sit tight against a wall or inside a media unit, or very small rooms, are often better served by bookshelf or in-wall speakers.

System Matching: AV Receiver, Speakers and Subwoofer

Pair with a centre from the same series. Most AV receivers drive 6-ohm loads; set the receiver's impedance option when the manufacturer recommends it.

• JBL Studio 690 — 2.5-way floorstanding loudspeaker
• JBL Studio 665C — centre channel loudspeaker
• JBL Studio 660P — powered subwoofer
• JBL Studio 610 — wall-mountable surround loudspeaker
• Choose a matching AV receiver — Denon, Marantz and Onkyo models with full specifications

Installation Guidance

What we check and do when installing this model:

• Space from the back wall to control port boom
• Tweeters near seated ear height, toed in to the seats
• Spikes or pads chosen for the floor finish (marble, tile, wood)
• Distance, level and crossover set before room correction

Why Buy the JBL Studio 698 Through LiveInSmart

LiveInSmart Technologies is an authorised JBL channel partner in Telangana and Andhra Pradesh, and a home-theatre and AV integrator with showrooms and demo rooms in Hyderabad (Ameerpet) and Vijayawada (Ashok Nagar). We help you choose JBL speakers for your room, match them with an AV receiver, then supply, install, calibrate and support the system — with 1000+ installations over the years and a 48-hour after-sales response.

• Help choosing the right model and speaker roles for your room
• Speaker and AV receiver matching
• Supply and delivery coordination
• Professional installation, configuration and testing
• Calibration and subwoofer integration
• Warranty coordination and upgrade advice

After-Sales Support

The team that installs your system supports it: 48-hour response, troubleshooting, recalibration after furniture or speaker changes, manufacturer warranty coordination and service escalation, and replacement or upgrade consultation.

JBL Studio 698 in Andhra Pradesh & Telangana

As an authorised JBL channel partner in Telangana and Andhra Pradesh, we supply, install and calibrate the JBL Studio 698 across Andhra Pradesh and Telangana from our Hyderabad and Vijayawada teams — including Nellore, Tirupati, Kurnool and Nandyal. Our showrooms are only in Hyderabad and Vijayawada; other cities start with a remote review of drawings and photos, followed by delivery and installation visits.
